• JL-05 made of aluminum alloy
    JL-05 load cell
    JL-05 Load Cell Features: For bench scale Specifications: Model JL-05 Model JL-05 Rated Capacities 60,100, 200,350, 500,800(kg) Output Impedance 350±5 Ω Rated Output 2.0 mV/V±5% Insulation Impedance ≥5000 MΩ/50VDC Non-linearity 0.02 %F.S Safe Overload 150 % F.S Hysteresis 0.02 % F.S Ultimate Overload 200 % F.S Repeatability 0.02 % F.S Operating Temperature Range -20~60 ℃ Creep(20min) 0.02 % F.S Recommended Excitation 5~12 VDC Temperature Effect On Output 0.002 % F.S /℃ Maximum Excitation 15 VDC Temperature  Effect On Zero 0.003 % F.S /℃ Construction Aluminum Alloy Zero Balance ±0.0200 mV/V Protection Class IP66 / IP67 Input Impedance 410±15 Ω Cable φ5×2 m Mode of Connection Red(EXC+),Black(EXC-),Green(SIG+),White(SIG-)
  • Multi-function GP 3120T Printer
    GP 3120T Barcode Printer
    GP 3120T Barcode Printer Features: ● 2M FLASH and DRAM memory; ● 3~5inch/s ultra-high print speed; ● Label paper auto position; ● Support Chinese and Korean Character; ● Support peel-off and tear-off modes; ● Compatible with various label software; ● Support BMP and PCX images download; ● Support parallel port, serial + USB port, Ethernet port; ● Support printing media width from 16mm to 80mm; ● Support parallel port, serial + USB port, Ethernet port; ● Auto temperature control for durable printing; Specification: Printing Print method Direct thermal line Resolution 203DPI Print speed 3 ~ 5inch/s Interface Serial + Parallel, USB + Ethernet Print head Temperature sensor: thermal sensitive resistance Pisition sensor: micro switch Paper presence Photoelectricity sensor Memory DRAM: 2M FLASH: 2M Character Size FONT O to FONT 8 Simplified/Traditional Chinese /Korean Barcode Enlargement & Rotation 1to10 times enlargement in both directions 0°、90°、270°、360°rotation Barcode mode UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/ CODABAR/CODE93/CODE128 Fonts GB2312 Media Media width 16 ~ 82mm Media diameter 25 ~ 85mm Power Cashdrawer out DC 24V/1A Power supply AC 110V/220V,50 ~ 60Hz,DC 24V/2A Physical properties Weight 1.5kg Dimension 220×150×150mm Environment Work environment Temperature: 0 ~ 45℃, Humidity: 10 ~ 80% Storage environment Temperature: -10 ~ 60℃ ,Humidity: 10 ~ 90%
  • JL-04 Load cell for bench  scale
    JL-04 Load cell for bench scale
    JL-04 Load cell for bench  scale  Model JL-04 Model JL-04 Rated Capacities 60,100, 200,350, 500,800(kg) Output Impedance 350±5 Ω Rated Output 2.0 mV/V±5% Insulation Impedance ≥5000 MΩ/50VDC Non-linearity 0.02 %F.S Safe Overload 150 % F.S Hysteresis 0.02 % F.S Ultimate Overload 200 % F.S Repeatability 0.02 % F.S Operating Temperature Range -20~60 ℃ Creep(20min) 0.02 % F.S Recommended Excitation 5~12 VDC Temperature Effect On Output 0.002 % F.S /℃ Maximum Excitation 15 VDC Temperature  Effect On Zero 0.003 % F.S /℃ Construction Aluminum Alloy Zero Balance ±0.0200 mV/V Protection Class IP66 / IP67 Input Impedance 410±15 Ω Cable φ5×2 m Mode of Connection Red(EXC+),Black(EXC-),Green(SIG+),White(SIG-)
  • JL-03 Load cell
    JL-03 Load cell for bench scale
    JL-03 Load cell for bench  scale
  • NA2 Load cell
    JADEVER JL-02 Load cell for bench scale
    JL-02 Load cell for bench  scale  Model JL-02 Model JL-02 Rated Capacities 60/100/150/200/250/300/350/500(kg) Output Impedance 350±5 Ω Rated Output 2.0 mV/V±5% Insulation Impedance ≥5000 MΩ Non-linearity 0.02 %F.S Safe Overload 150 %F.S Hysteresis 0.02 %F.S Ultimate Overload 200 %F.S Repeatability 0.02 %F.S Operating Temperature Range -20~60 ℃ Creep(20min) 0.02 %F.S Recommended Excitation 5~12 VDC Temperature Effect On Output 0.002 %F.S/℃ Maximum Excitation 15 VDC Temperature  Effect On Zero 0.003 %F.S/℃ Construction Aluminum Alloy Zero Balance ±0.0200 mV/V Protection Class IP67 / IP68 Input Impedance 410±15 Ω Cable φ5×15 cm Mode of Connection Red(EXC+),Black(EXC-),Green(SIG+),White(SIG-)
  • JWP waterproof Load cell
    JWP waterproof Load cell
    Main technical data Rated load kg 3/5/10/20/40 Accuracy class C3 Maxinum number of load cell verification intervals nmax nmax Minimum load cell verification intervals Vmin Vmin Combined error %FS %FS Creep  %FS/30min %FS/30min Temp. effect on sensitivity %FS/10℃ %FS/10℃ Temp. effect on zero output %FS/10℃ %FS/10℃ Sensitivity  mv/v 2.0±0.2 Input resistance  Ω 406±6 Output resistance Ω 350±3 Insulation resistance MΩ ≥5000(50VDC) Zero output %FS ≤±2 Compensated temperature range ℃ -10~40 Operating temperature range ℃ -35~65 Recommended excitation voltage V 5~12(DC) Maximum excitation voltage V 16(DC) Safe over load  %FS 150 Ultimate over load %FS 300 Four comer error  0.02% load value Maximum table size mm 250×250
1 2 3

A total of 3 pages
