JL-05 load cell

  • Brand:

    JADEVER
  • Item NO.:

    JL-05 load cell
  • Product Origin:

    China
  • Product Detail

JL-05 Load Cell

Features: For bench scale

Specifications:


Model

JL-05

Model

JL-05

Rated Capacities

60,100, 200,350, 500,800kg

Output Impedance

350±5 Ω

Rated Output

2.0 mV/V±5%

Insulation Impedance

5000 MΩ/50VDC

Non-linearity

0.02 %F.S

Safe Overload

150 % F.S

Hysteresis

0.02 % F.S

Ultimate Overload

200 % F.S

Repeatability

0.02 % F.S

Operating Temperature Range

-20~60

Creep(20min)

0.02 % F.S

Recommended Excitation

5~12 VDC

Temperature Effect On Output

0.002 % F.S /

Maximum Excitation

15 VDC

Temperature  Effect On Zero

0.003 % F.S /

Construction

Aluminum Alloy

Zero Balance

±0.0200 mV/V

Protection Class

IP66 / IP67

Input Impedance

410±15 Ω

Cable

φ5×2 m

Mode of Connection

RedEXC+,BlackEXC-,GreenSIG+,WhiteSIG-
