What are the features of JWI-2100 indicator?

v  Dark grey industrial ABS housing, red LED digital display(Customized green or blue LED display is acceptable)

v  Standard overlay, Neutral overlay, customized overlay is acceptable

v  Mechanical keypad with matte overlay

v  The reinforcement design of the plastic adapter bracket is strong and firm

v  6V/4Ah Rechargeable battery, Build-in transformer and power cord for power supply

v  Up to 1-4×350Ω Load cell and can be used with different sizes of bench scales

v  Optional: RS232,Printer, Large LED screen, Relay

v  With Peak hold and animal weighing function, optional extended modules: Bluetooth, Wifi, Network port, U-disk module,

v  Ideal for production, shipping areas

function of JWI-2100 Weighing indicator

HoLd–0:No hold function

HoLd–1:Hold peak value. Press UNIT/SET key to release, press +/PRINT/HI to print HOLD value

HoLd–2:Hold after stable. Press any key to release

HoLd–3:Hold after stable. Release after moving away the article. The hold value is based on the current value and its range could be set in sub menu. Accumulation hold function is available, that is you could add article after hold the first value.

HoLd–4:Press key -/HOLD/LO/ to hold. Press any key to release

HoLd –5:Hold automatically.(Optional dynamic animal weighing function).

Note: It only can work when weighing value ≥20d

Sub menu for Hold 3: INF (default: infinity) /10 /20 /50 /100 /200 /500 /1000/2000 /5000 /10000 /20000 /50000

H=current hold value, R=hold value range, d= division, W= actual weight

Keep to hold the value when |W-H|<=R*d, or the scale will exit the hold function. The scale will cancel the hold function when empty the weighing pan, if choose INF setting.

Sub menu for Hold 5: default hold value arrange (HD): 0100

Disable the hold function automatically: |CW-CH| > HD*d, CW=actual weight, CH=current hold value, HD=hold value arrange.

Disable the hold function manual: press HOLD button to cancel the current hold value.

Specifications:
