stainless steel floor scale with ramp for weighing indicator

The Jadever low profile floor scale has a 2” deck height, making it easy to load and unload goods with forklift trucks and hand carts.

JADEVER JLM Pallet Truck Scale helps you easy and safely move heavier loads with weight displayed on the weighing indicator.

Jadever Roller Conveyor Scale is built to allow easy weighing and movement of cargo, with indicator has HI,LO,OK checkweighing, can support quickly indentify whe weighing below the standard.

Floor scales are perfect for heavy duty weighing, They can be loaded with ease using a fork truck. If the optional ramps option is selected they are also suitable for loading via pallet truck.

Main technical data Rated load kg 3/5/10/20/40 Accuracy class C3 Maxinum number of load cell verification intervals nmax nmax Minimum load cell verification intervals Vmin Vmin Combined error %FS %FS Creep  %FS/30min %FS/30min Temp. effect on sensitivity %FS/10℃ %FS/10℃ Temp. effect on zero output %FS/10℃ %FS/10℃ Sensitivity  mv/v 2.0±0.2 Input resistance  Ω 406±6 Output resistance Ω 350±3 Insulation resistance MΩ ≥5000（50VDC） Zero output %FS ≤±2 Compensated temperature range ℃ -10～40 Operating temperature range ℃ -35～65 Recommended excitation voltage V 5～12（DC） Maximum excitation voltage V 16（DC） Safe over load  %FS 150 Ultimate over load %FS 300 Four comer error  0.02% load value Maximum table size mm 250×250

Features: ●Eco-Product; High efficiency and economical ●Large LCD display with green L ED backlight ●Zero/Tare/Simple/Weighing/Simple counting/Accumulation /Net & Gross weight/Check weighing function ●Adjustable capacities, resolutions and parameters ● Supports to four analog load cells ●Power saving design with high efficiency and environment protection. ●Convenient with three power options: Solar energy, Adapter, Li-ion Battery ●In times of strong sunlight, 4 pieces of high quality solar energy panels can provide up to 200mA charging current ●It can work as long as there is sunlight ( no need of direct radiation).And battery is under charging at the same time ●Li-ion battery can be repeatedly used with long service life ●When the battery is fully charged, it can operate normally for up to 200h. When used in a light place, the solar energy will continue to charge the battery, so the indicator can be used for a longer period of time. ●Ideal for applications in outside market, production, packaging, warehouse, inventory, shipping and receiving areas or any other place where power supply is inconvenient Specifications： Model JWI-700S Resolution 1/15000 Weighing Unit pcs /台斤/ lb.oz /  g / kg Display 6 digits, 30mm digit height, LCD display with green LED backlight Dimension(mm) 274 x170x117 Weight Net weight:0.8kg   Gross weight:1 .9kg Power supply Solar energy; 4000mA Li-ion battery; 6V/300mA adapter Load cell excitation DC 3.3v,up to 4 x 350 ohm load cells Certification CE

JWI-531 Waterproof Indicator Features: ●304 stainless steel housing ●Fully sealed circuit board design, with waterproof, moisture-proof, dust-proof performance ● Functions of pre-tare, checkweighing, accumulation, animal weighing, low battery alert, etc. ●Single and multi-point calibration to ensure accuracy ●Filter level and weighing speed can be selected according to the environment ●Optional RS-232 interface ●Widely used in high humidity environments, seafood markets, food processing plants, etc. Specification: Model JWI-531 External Display Accuracy 1/12000  or  1/15000 Unit Selection kg、g、lb、lb.oz/斤、pcs Display Screen (mm) 6-digit LED red display character height 25 Input Sensitivity 0.2 microvolts/division Input Voltage Range -2 mV~20 mV Sensor Excitation Voltage DC 5V, can be connected to four 350 ohm sensors Non-linearity 0.003% of full scale weight Input Impedance Greater than 10×106 ohms A/D conversion method △-Σ A/D internal resolution 700,000 A/D conversion output period Approx  6~10 times per second Power supply AC: 110/220V, with built-in lead-acid battery (6V/4Ah) External Dimension(mm) 238×94×145
