U-disk connection module for weighing scale

JADEVER U-disk connection module can help save the weighing data in U-disk,the data can be seen in the excel when plug the U-disk into the PC

Brand:
JADEVER
Item NO.:
U-disk connection mo
Product Origin:
China

Inquiry now

Categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Detail

Features:
converts weighing data to excel file stored in U-disk
weighing data including serial number,date, time, etc.
only store the weight data if the weight is within OK range

User Guidance:
1.U-disk module installed into the scale
2.Plug the U-disk into the scale USB port
3. the data can be seen in the excel when plug the U-disk into the PC

Videos:

1. JWQ with scanner can save weight data and bar-code info into U-disk

1) JWQ install U-disk & USART module inside and a USB port outside, plug a U-disk into the scale

2) setup JWQ external connector as U-disk & scanner

3) Put the item on the scale and scan the bar-code on the label at the same time, the weight data and bar code info will stored on the U-disk

4) plug the U-disk into the PC, open the excel file on the U-disk

2. customized U-disk case：JWI-700C save weighing data in U-disk in groups with bar-code scanner,

10 items a group, one row one group, three rows are three groups of operations.
